面向临床需求的CT图像降噪综述

doi:10.11871/jfdc.10-1649.2021.06.003

数据与计算发展前沿 ›› 2021, Vol. 3 ›› Issue (6): 35-49.

doi: 10.11871/jfdc.10-1649.2021.06.003

• 专刊:科学大数据挖掘与知识发现 • 上一篇下一篇

面向临床需求的CT图像降噪综述

蒲晓蓉^1,^*(),黄佳欣¹(),刘军池¹(),孙家瑜²(),罗纪翔¹(),赵越¹(),陈柯成¹(),任亚洲¹()

1. 电子科技大学,计算机科学与工程学院,大数据研究中心,四川成都 611731
2. 四川大学华西医院,四川成都 610044

收稿日期:2021-11-15 出版日期:2021-12-20 发布日期:2022-01-26
通讯作者: 蒲晓蓉
作者简介:蒲晓蓉, 电子科技大学计算机科学与工程学院,博士,教授,主要研究方向包括人工神经网络、机器学习、计算机视觉、医学图像处理、计算机辅助诊断 (CAD)、智能健康医疗。
负责制定论文框架,撰写“引言”与“结论与展望”,论文修改、审定。
PU Xiaorong, Ph.D., is currently a professor with the School of Computer Science and Engineering, University of Electronic Science and Technology of China, Chengdu, China. Her current research interests include neural networks, computer vision, computer aided diagnosis (CAD), and e-Health.
In this paper, she is responsible for drawing up the paper framework, writing “Introduction” and “Conclusion and Outlook”, and paper revision and approval. E-mail: puxiaor@uestc.edu.cn;|黄佳欣,电子科技大学计算机科学与工程学院,硕士研究生,研究方向为计算机视觉、医学图像处理。
负责论文初稿撰写,并研究有关从LDCT图像中学习噪声的降噪方法。
HUANG Jiaxin is pursuing the M.Sc. degree in computer science and technology with the School of Computer Science and Engineering, University of Electronic Science and Technology of China, Chengdu, China, under the supervision of Prof. X. Pu. Her research interests include computer vision and medical image processing.
In this paper, she is responsible for the paper drafting and research on noise reduction methods for learning noise from LDCT images. E-mail: jiaxinhuang011403@gmail.com;|刘军池,电子科技大学计算机科学与工程学院,硕士研究生,研究方向为医学图像分析。
参与撰写“2 面向临床需求的LDCT图像降噪方法”。
LIU Junchi is pursuing the M.Sc. degree in computer science and technology with the School of Computer Science and Engineering, University of Electronic Science and Technology of China, Chengdu, China, under the supervision of Prof. X. Pu. His research interests include medical image processing.
In this paper, he is responsible for writing “2 LDCT image denoising method clinical-oriented LDCT image denoising”. E-mail: jchiliu@163.com;|孙家瑜,四川大学华西临床医学院（华西医院）,教授,2021年获四川大学医学技术博士学位,主要研究方向包括医学成像技术和医学图像深度挖掘。
参与撰写“3 医学图像质量评价”部分。
SUN Jiayu is currently a professor of School of clinical medicine of West China (West China Hos-pital) of Sichuan University. He received the MD.D. degree in medical technology, from Sichuan University, Chengdu, China in 2021. His current research interests include medical imaging technology and deep mining of medical images.
In this paper, he is responsible for writing “3 Medical image quality evaluation”. E-mail: sjy080512@163.com;|罗纪翔,电子科技大学计算机科学与工程学院,硕士研究生,主要研究方向为计算机视觉、医学图像处理。
参与撰写“1.1 传统低剂量CT图像降噪研究方法”部分。
LUO Jixiang is pursuing the M.Sc. degree in computer science and technology with the School of Computer Science and Engineering, University of Electronic Science and Technology of China, Chengdu, China, under the supervision of Prof. X. Pu. His main research interests include computer vision and medical image processing.
In this paper, he is responsible for writing “1.1 Traditional low-dose CT image denoising research method”. E-mail: galaxyluo@outlook.com;|赵越,电子科技大学计算机科学与工程学院,硕士研究生,主要研究方向为计算机视觉和医学图像处理。
参与撰写“1.2 基于深度学习的LDCT图像降噪方法”部分。
ZHAO Yue is pursuing the M.Sc. degree in computer science and technology with the School of Com-puter Science and Engineering, University of Electronic Science and Technology of China, Chengdu, China, under the supervision of Prof. X. Pu. His main research interests include computer vision and medical image processing.
In this paper, he is responsible for writing “1.2 Denoising me-thod of LDCT image based on deep learning”. E-mail: kennyZ96@hotmail.com;|陈柯成,电子科技大学计算机科学与工程学院,硕士研究生,主要研究方向为机器学习、医学图像处理。
参与撰写“2 面向临床需求的LDCT图像降噪方法”,并研究基于协同训练的LDCT图像降噪。
CHEN Kecheng is pursuing the M.Sc. degree in computer science and technology with the School of Computer Science and Engineering, University of Electronic Science and Tech-nology of China, Chengdu, China, under the supervision of Prof. X. Pu. His research interests include machine learning, medical image processing and big data.
In this paper, he is responsible for writing “2 LDCT image denoising method clinical-oriented LDCT image denoising”, and research on denoising of LDCT image based on co-training. E-mail: cs.ckc96@gmail.com;|任亚洲,电子科技大学计算机科学与工程学院,副教授,分别于2009年和2014年在华南理工大学获信息与计算科学学士学位以及计算机应用技术博士学位,2012年至2014年访问美国乔治梅森大学的数据挖掘实验室。共发表50多篇同行评议的学术论文,目前的研究方向包括机器学习和医学数据分析。
参与制定论文框架与论文修改、审定。
REN Yazhou is currently an associate professor with the School of Computer Science and Engineering, University of Electronic Science and Technology of China, Chengdu, China. He recei-ved the B.Sc. degree in information and computation science and the Ph.D. degree in computer science from the South China University of Technology, Guangzhou, China, in 2009 and 2014, respectively. He visited the Data Mining Laboratory, George Mason University, USA, from 2012 to 2014. He has published more than 50 peer-reviewed research articles. His current research interests include machine learning and medical data analysis.
In this paper, he is responsible for drawing up the paper frame-work and paper revision and approval. E-mail: yazhou.ren@uestc.edu.cn
基金资助:
四川省科技计划项目重点项目(2020YFS0119);四川省科技计划项目重点项目(2021YFS0172);国家自然科学基金项目(61806043);2021年成都市技术创新研发项目(2021-YF05-01583-SN);四川大学华西医院学科卓越发展1·3·5工程临床研究孵化项目(2021HXFH004)

A Survey on Clinical Oriented CT Image Denoising

PU Xiaorong^1,^*(),HUANG Jiaxin¹(),LIU Junchi¹(),SUN Jiayu²(),LUO Jixiang¹(),ZHAO Yue¹(),CHEN Kecheng¹(),REN Yazhou¹()

1. School of Computer Science and Engineering, Big Data Research Center, University of Electronic Science and Technology of China, Chengdu, Sichuan 611731, China
2. West China Hospital, Sichuan University, Chengdu, Sichuan 610044, China

Received:2021-11-15 Online:2021-12-20 Published:2022-01-26
Contact: PU Xiaorong

摘要/Abstract

摘要：

【目的】低剂量CT扫描技术已广泛用于肺结节和肺癌早期筛查等临床诊断。然而,由辐射剂量降低所导致的成像噪声制约着诊断精度的进一步提高。【方法】本文综合研究了低剂量CT图像降噪技术的发展脉络,从基于迭代优化等传统方法出发,分析了当前基于机器学习技术的低剂量CT图像降噪等CT图像降噪方法。【结果】现有基于机器学习的CT图像降噪方法,一方面采用人为假设噪声分布并构造人工数据集进行模型训练和测试,忽略了临床应用中噪声特点和强度的多样性问题;另一方面,由于深度神经网络的“黑盒”特性,导致现有基于深度神经网络的低剂量CT图像降噪模型的可解释性不足。【结论】CT图像降噪应面向临床实际需求,充分考虑噪声形成的机理和图像噪声的真实分布,结合病灶检测等高阶任务和临床医生的阅片行为,探索面向临床需求的低剂量CT图像降噪新范式。

关键词: CT图像, 深度学习, 图像降噪, 图像质量评价

Abstract:

[Objective] Low-dose CT scanning technology has been widely used in clinical diagnoses such as early screening of lung nodules and lung cancer. However, the imaging noise caused by the reduction of radiation dose has restricted the further improvement of diagnostic accuracy.[Methods] This article comprehensively studies the development of low-dose CT image noise reduction technology. Starting with the traditional methods such as iterative optimization, it analyzes the current methods of low-dose CT image noise reduction based on machine learning. [Results] The existing methods based on machine learning, on the one hand, use artificially assumed noise distribution and construct artificial data sets to train and test the model, ignoring the diverse characteristics and intensity of noise in clinical applications; on the other hand, due to the "black box" characteristics of deep neural networks, the existing low-dose CT image noise reduction models based on deep neural networks are insufficient in interpretability. [Conclusions] CT image noise reduction should be oriented to the requirements of clinical scenarios, fully consider the mechanism of noise formation and the true distribution of image noise, and combine high-level tasks such as lesion detection and the reading behavior of clinicians to explore the brand-new paradigm of low-dose CT image noise reduction for clinical demands.

Key words: CT image, deep learning, image denoising, image quality evaluation

蒲晓蓉,黄佳欣,刘军池,孙家瑜,罗纪翔,赵越,陈柯成,任亚洲. 面向临床需求的CT图像降噪综述[J]. 数据与计算发展前沿, 2021, 3(6): 35-49.

PU Xiaorong,HUANG Jiaxin,LIU Junchi,SUN Jiayu,LUO Jixiang,ZHAO Yue,CHEN Kecheng,REN Yazhou. A Survey on Clinical Oriented CT Image Denoising[J]. Frontiers of Data and Computing, 2021, 3(6): 35-49.

图/表 5

图1

表1

表2

图2

图3

参考文献 61

[1]	Pan T. Computed Tomography: from Photon Statistics to Modern Cone-Beam CT[J]. Journal of Nuclear Medicine, 2009,50(7):1194.
[2]	张秀文, 张永寿, 刘乃智. PET-CT工作原理及应用[J]. 中国医学装备, 2012, ( 11):22-25.
[3]	石明国. 实用CT影像技术学[M]. 西安: 陕西科学技术出版社, 1995: 233-235.
[4]	朱兆丰. CT图像中噪声产生机理与维修[J]. 中国医疗设备, 2005,20(11):50-51.
[5]	Naidich D P, Marshall C H, Gribbin C, et al. Low-dose CT of the lungs: Preliminary observations[J]. Radiology, 1990,175(3):729-731.
[6]	吴宁, 赵世俊. 积极规范地开展低剂量螺旋CT肺癌筛查[J]. 中华放射学杂志, 2015(5):2.
[7]	Guo L, Chen Q, Shen Y, et al. Evaluation of a Low-Dose Computed Tomography Lung Cancer Screening Program in Henan, China[J]. JAMA Network Open, 2020,3(11):e2019039.
[8]	Shi J, Wang L, Wang S, Chen Y, et al. 2020. Applications of deep learning in medical imaging: a survey. Journal of Image and Graphics, 25(10):1953-1981.
[9]	Wang J, Lu H, Li T, et al. Sinogram noise reduction for low-dose CT by statistics-based nonlinear filters[C]. Image Processing pt.3, Progress in Biomedical Optics and Imaging, 2005,6(24):2058-2066.
[10]	Mileto A, Guimaraes L, Mccollough C, et al. State of the Art in Abdominal CT: The Limits of Iterative Recons-truction Algorithms[J]. Radiology, 2019,293(3):491-503.
[11]	Li M, Hsu W, Xie X, et al. SACNN: Self-Attention Con-volutional Neural Network for Low-Dose CT Denoising with Self-supervised Perceptual Loss Network[J]. IEEE Transactions on Medical Imaging, 2020,39(7):2289-2301.
[12]	Hara A, Paden R, AC Silva, et al. Iterative reconstruction technique for reducing body radiation dose at CT: feasi-bility study[J]. American Journal of Roentgenology, 2009,193(3):764-771.
[13]	Sidky E, Pan X. Image reconstruction in circular cone-beam computed tomography by constrained, total-variation minimization[J]. Physics in Medicine & Bio-logy, 2008,53(17):4777-4807.
[14]	Yang C, Gao D, Cong N, et al. Bayesian statistical recon-struction for low-dose X-ray computed tomography using an adaptive-weighting nonlocal prior[J]. Computerized Medical Imaging & Graphics, 2009,33(7):495-500.
[15]	Xu Q, Yu H, Mou X, et al. Low-dose X-ray CT reconstr-uction via dictionary learning[J]. IEEE transactions on medical imaging, 2012,31(9):1682-1697.
[16]	Cai J, Jia X, Gao H, et al. Cine cone beam CT reconstruction using low-rank matrix factorization: algorithm and a proof-of-principle study[J]. IEEE transactions on medical imaging, 2014,33(8):1581-1591.
[17]	Li Z, Yu L, Trzasko J D, et al. Adaptive nonlocal means filtering based on local noise level for CT denoising[J]. Medical physics, 2014,41(1):11908.
[18]	Feruglio P, Vinegoni C, Gros J, et al. Block matching 3D random noise filtering for absorption optical projection tomography[J]. Physics in Medicine & Biology, 2010,55(18):5401-5415.
[19]	Chen H, Zhang Y, Zhang W, et al. Low-dose CT den-oising with convolutional neural network[C]. 2017 IEEE 14th International Symposium on Biomedical Imaging (ISBI 2017), 2017: 143-146.
[20]	Chen H, Zhang Y, Kalra M K, et al. Low-dose CT with a residual encoder-decoder convolutional neural network[J]. IEEE transactions on medical imaging, 2017,36(12):2524-2535.
[21]	Mao X, Shen C, Yang Y. Image restoration using very deep convolutional encoder-decoder networks with sym-metric skip connections[C]. In Proceedings of the 30 ^th International Conference on Neural Information Proce-ssing Systems (NIPS’16) , 2016: 2810-2818.
[22]	He K, Zhang X, Ren S, et al. Deep residual learning for image recognition[C]. Proceedings of the IEEE confe-rence on computer vision and pattern recognition, 2016: 770-778.
[23]	Hu C, Zhang Y, Zhang W, et al. Low-dose CT via convo-lutional neural network[J]. Biomedical Optics Express, 2017,8(2):679-694.
[24]	Yang Q, Yan P, Kalra M K, et al. CT image denoising with perceptive deep neural networks[J]. arXiv preprint arXiv: 1702. 07019, 2017.
[25]	Simonyan K, Zisserman A. Very Deep Convolutional Networks for Large-Scale Image Recognition[C]. The 3rd International Conference on Learning Representations (ICLR2015). https://arxiv.org/abs/1409.1556.
[26]	张雄, 杨琳琳, 上官宏等. 基于生成对抗网络和噪声水平估计的低剂量CT图像降噪方法[J]. 电子与信息学报, 2021,43(8):2404-2413.
[27]	Gholizadeh-Ansari M, Alirezaie J, Babyn P. Low-dose CT Denoising with Dilated Residual Network[C]. 40 ^th Annual International Conference of the IEEE Engineering in Medicine and Biology Society (EMBC) , 2018: 5117-5120.
[28]	Kadimesetty V S, Gutta S, Ganapathy S, et al. Convo-lutional Neural Network-Based Robust Denoising of Low-Dose Computed Tomography Perfusion Maps[J]. IEEE Transactions on Radiation and Plasma Medical Sciences, 2018,3(2):137-152.
[29]	Liu P, Li Y, Basha M, et al. Neural Network Evolution Using Expedited Genetic Algorithm for Medical Image Denoising[C]. Medical Image Computing and Computer Assisted Intervention - MICCAI, 2018: 12-20.
[30]	Han Y, Ye J. Framing U-Net via Deep Convolutional Fra-melets: Application to Sparse-View CT[J]. IEEE Tran-sactions on Medical Imaging, 2018,37(6):1418-1429.
[31]	Khoroushadi M, Sadegh M. Enhancement in low-dose computed tomography through image denoising techniques: Wavelets and deep learning[D]. Ph.D. thesis, ProQuest Dissertations Publishing. 2018.
[32]	Green M, Marom E, Konen E, et al. Learning Real Noise for Ultra-Low Dose Lung CT Denoising[C]. Patch-Based Techniques in Medical Imaging, 2018: 3-11.
[33]	Li M, Hsu W, X Xie, et al. SACNN: Self-Attention Con-volutional Neural Network for Low-Dose CT Den-oising with Self-supervised Perceptual Loss Network[J]. IEEE Transactions on Medical Imaging, 2020,39(7):2289-2301.
[34]	Hendriksen A A, Pelt D M, Batenburg K J. Noise2Inverse: Self-supervised deep convolutional denoising for linear inverse problems in imaging[J]. IEEE Transactions on Computational Imaging, 2020,6:1320-1335.
[35]	Wu D, Ren H, Li Q. Self-supervised Dynamic CT Per-fusion Image Denoising with Deep Neural Networks[J]. IEEE Transactions on Radiation and Plasma Medical Sciences, 2021,5(3):350-361.
[36]	Du W, Chen H, Yang H. Learning Invariant Representa-tion for Unsupervised Image Restoration[C]. 2020 IEEE/CVF Conference on Computer Vision and Pattern Recog-nition (CVPR), 2020: 14471-14480.
[37]	Chen K, Long K, Ren Y, Sun J, Pu X. Lesion-Inspired Denoising Network: Connecting Medical Image Denoi-sing and Lesion Detection[C]. Proceedings of the 29th ACM International Conference on Multimedia, 2021: 3283-3292.
[38]	Wolterink J M, Leiner T, Viergever M A, et al. Generative adversarial networks for noise reduction in low-dose CT[J]. IEEE transactions on medical imaging, 2017,36(12):2536-2545.
[39]	Isola P, Zhu J Y, Zhou T, et al. Image-to-Image Tra-nslation with Conditional Adversarial Networks[C]. 2017 IEEE Conference on Computer Vision and Pattern Recog-nition (CVPR), 2017: 5967-5976.
[40]	Goodfellow I J, Pouget-Abadie J, Mirza M, et al. Gene-rative Adversarial Networks[J]. Advances in Neural Infor-mation Processing Systems, 2014,3:2672-2680.
[41]	Burlina P M, Joshi N, Pekala M, et al. Automated grading of age-related macular degeneration from color fundus images using deep convolutional neural networks[J]. JAMA ophthalmology, 2017,135(11):1170-1176.
[42]	Maas A L, Hannun A Y, Ng A Y. Rectifier Nonlinearities improve neural network acoustic models[C]. In Proc. ICML, 2013,30(1):3.
[43]	Glorot X, Bengio Y. Understanding the difficulty of training deep feedforward neural networks[C]. Procee-dings of the thirteenth international conference on artifi-cial intelligence and statistics. JMLR Workshop and Con-ference Proceedings, 2010: 249-256.
[44]	Yu A, Liu X, Wei X, et al. Generative Adversarial Netw-orks with Dense Connection for Optical Coherence Tomo-graphy Images Denoising[C]. 2018 11th Intern-ational Congress on Image and Signal Processing, BioMedical Engineering and Informatics (CISP-BMEI), 2018: 1-5.
[45]	Abbasi A, Monadjemi A, Fang L, et al. Three-dim-ensional optical coherence tomography image denoising through multi-input fully-convolutional networks[J]. Computers in Biology and Medicine, 2019,108:1-8.
[46]	Ma Y, Chen X, Zhu W, et al. Speckle noise reduction in optical coherence tomography images based on edge-sensitive cGAN[J]. Biomedical optics express, 2018,9(11):5129-5146.
[47]	Hong Z, Fan X, Jiang T, et al. End-to-End Unpaired Image Denoising with Conditional Adversarial Networks[J]. Proceedings of the AAAI Conference on Artificial Intelli-gence, 2020,34(4):4140-4149.
[48]	Park H S, Baek J, You S K, et al. Unpaired image denoi-sing using a generative adversarial network in X-ray CT[J]. IEEE Access, 2019,7:110414-110425.
[49]	You C, Yang Q, Shan H, et al. Structurally-sensitive Mul-ti-scale Deep Neural Network for Low-Dose CT Denoi-sing[J]. IEEE Access, 2018,6:41839-41855.
[50]	Yang Q, Yan P, Zhang Y, et al. Low-Dose CT Image De-noising Using a Generative Adversarial Network with Wasserstein Distance and Perceptual Loss[J]. IEEE Tran-sactions on Medical Imaging, 2018,37(6):1348-1357.
[51]	Chen K, Huang J, Sun J, et al. Task-Driven Deep Lear-ning for LDCT Image Denoising[C]. In The Fourth Inter-national Symposium on Image Computing and Digital Medicine. Association for Computing Machinery, New York, NY, USA, 2020: 35-39.
[52]	段影影. 医学图像质量评价方法研究[D]. 广东:南方医科大学, 2010.
[53]	Shan H, Padole A, Homayounieh F, et al. Competitive performance of a modularized deep neural network com-pared to commercial algorithms for low-dose CT image reconstruction[J]. Nature Machine Intelligence, 2019,1(6):269-276.
[54]	段影影, 马建华, 陈武凡, 等. 改进的结构相似医学图像质量评价方法[J]. 计算机工程与应用, 2010,46(2):145-149.
[55]	张剑华, 张自然, 汪晓妍, 等. 基于结构显著性的医学图像质量评价[J]. 浙江工业大学学报, 2015,43(6):636-641.
[56]	Virendra K, Gu Y, Satrajit B, et al. Radiomics: the pro-cess and the challenge[J]. Magnetic Resonance Imaging, 2012,30(9):1234-1248.
[57]	陆锐, 何健, 周科峰, 等. 自动管电流调制扫描及ASIR重建下胸部CT噪声指数的优化[J]. 医学影像学杂志, 2016,26(06):1012-1016.
[58]	Junior F, Raniery R, Koenigkam-Santos M, Cipriano F, et al. Radiomics-based features for pattern recognition of lung cancer histopathology and metastases[J]. Computer Methods and Programs in Biomedicine, 2018,159:23-30.
[59]	Zhang Q, Xiao Y, Suo J, et al. Sonoelastomics for Breast Tumor Classification: A Radiomics Approach with Clustering-Based Feature Selection on Sonoelastography[J]. Ultrasound in medicine & biology, 2017,43(5):1058-1069.
[60]	Coroller T, Grossmann P, Hou Y, et al. CT-Based radiomic signature predicts distant metastasis in lung adenocar-cinoma[J]. Radiotherapy and Oncology, 2015,114(3):345-350.
[61]	Visvikis D, Rest C, Jaouen V, et al. Artificial intelligence, machine (deep) learning and radio(geno)mics: definitions and nuclear medicine imaging applications[J]. European Journal of Nuclear Medicine, 2019,46(13):2630-2637.

参考文献	噪声类型	应用场景	关键词	评价指标
Gholizadeh等 (2018) ^[27]	外加白噪声	LDCT/X射线图像降噪	膨胀卷积	PSNR\SSIM
Kadimesetty等 (2019) ^[28]	外加白噪声	LDCT图像降噪	强化学习/批归一化	PSNR\SSIM
Liu等 (2018) ^[29]	外加白噪声	CT灌注图像降噪	遗传算法	PSNR\SSIM\RMSE
Han等(2018)^[30]	真实噪声	CT图像重建	U-Net/跳跃连接	PSNR\SSIM
Khoroushadi等(2019) ^[31]	真实噪声	LDCT图像降噪	小波变换	PSNR\SSIM
Green等(2018) ^[32]	真实噪声	肺部超低剂量CT图像降噪	卷积神经网络	PSNR\双盲评分
Li等(2020) ^[33]	真实噪声	LDCT图像降噪	自注意力/自监督	PSNR\SSIM\RMSE
Hendriksen等(2020) ^[34]	真实噪声	LDCT图像降噪	自监督/无配对样本	PSNR\SSIM\RMSE
Wu等(2020)^[35]	真实噪声	CT灌注图像降噪	自监督/无配对样本	PSNR\SSIM
Du等(2020)^[36]	真实噪声	图像超分/LDCT图像降噪	无监督/域适应	PSNR\SSIM\RMSE
Chen等(2021)^[37]	真实噪声	LDCT图像降噪	协同训练	PSNR\双盲评分
Chen等(2020)^[51]	真实噪声	LDCT图像降噪	构造成对伪样本	PSNR\SSIM

参考文献	噪声类型	应用场景	关键词	评价指标
Yu等 (2018) ^[44]	外加白噪声	光学相干层析成像降噪	深度网络/跳跃连接	PSNR\SSIM\RMSE
Abbasi等(2019) ^[45]	外加白噪声	3D-MRI/LDCT图像降噪	强化学习/全卷积网络	PSNR\SSIM
Ma等(2018) ^[46]	真实噪声	光学相干层析成像降噪	GAN/边缘优先	PSNR\SSIM\RMSE
Hong等(2020) ^[47]	真实噪声	CT图像重建	CGAN/端到端网络	PSNR\SSIM
Park等(2019)^[48]	真实噪声	LDCT图像降噪	GAN/无监督	PSNR\SSIM\RMSE
You等(2018) ^[49]	真实噪声	LDCT图像降噪	GAN/无监督	PSNR\双盲评分
Yang等(2018) ^[50]	真实噪声	LDCT图像降噪	WGAN/感知损失	PSNR\双盲评分
Zhang等(2021)^[26]	真实噪声	LDCT图像降噪	U-Net	PSNR\SSIM\RMSE
