数据与计算发展前沿 ›› 2022, Vol. 4 ›› Issue (4): 114-122.

CSTR: 32002.14.jfdc.CN10-1649/TP.2022.04.011

doi: 10.11871/jfdc.issn.2096-742X.2022.04.011

• 专刊： 北斗导航数据处理 • 上一篇    下一篇

BDS/Galileo融合精密单点定位性能评估

张京奎1,2,*(),周鹏3,陈永昌1,2,盛传贞1,2

  1. 1.卫星导航系统与装备技术国家重点实验室,河北 石家庄 050081
    2.中国电子科技集团公司第五十四研究所,河北 石家庄 050081
    3.中国计量科学研究院,北京 100029
  • 收稿日期:2022-04-11 出版日期:2022-08-20 发布日期:2022-08-10
  • 通讯作者: 张京奎
  • 作者简介:张京奎,中国电子科技集团公司第五十四研究所,博士研究生,工程师,主要研究方向为PPP、PPP-RTK定位等方面高精度数据处理工作。
    本文中负责实验设计、数据分析、文稿撰写等工作。
    ZHANG Jingkui, a Ph.D. candidate, is an engineer at the CETC 54th Research Institute. His research interests include high-precision data processing in time-freque-ncy transmission and PPP-RTK positioning.
    In this work, he is responsible for experimental design, exper-imental processing, and manuscript writing.
    E-mail: cetc_zjk@163.com
  • 基金资助:
    河北省省级科技计划资助(206Z0303G);中国电子科技集团公司技术创新基金“天地协同PNT网络关键技术研究”(BAX20684X010);中国电子科技集团公司第五十四研究所发展基金“新一代天地协同PNT网络”(SCX20684X012)

Assessment of BDS/Galileo Precise Point Positioning with Ambiguity Resolution

ZHANG Jingkui1,2,*(),ZHOU Peng3,CHEN Yongchang1,2,SHENG Chuanzhen1,2

  1. 1. State Key Laboratory of Satellite Navigation System and Equipment Technology, Shijiazhuang, Hebei 050081, China
    2. The 54th Research Institute of CETC, Shijiazhuang, Hebei 050081, China
    3. National Institute of Metrology, Beijing 100029, China
  • Received:2022-04-11 Online:2022-08-20 Published:2022-08-10
  • Contact: ZHANG Jingkui

RichHTML

12

PDF

109

摘要：

【目的】针对传统精密单点定位（Precise Point Positioning, PPP）模糊度非整数特征的问题,基于整数钟产品完成模糊度的固定,验证单Galileo系统PPP模糊度固定对定位性能的影响以及BDS/Galileo双系统组合相比单Galileo系统在定位性能方面和模糊度固定率方面的提升。【方法】基于真实数据开展实验验证,通过解算单Galileo及BDS/Galileo双系统组合PPP模糊度固定模式下定位精度跟模糊度浮点解模式下进行比较,评估不同模式下的定位性能及模糊度固定率的提升。【结果】单Galileo系统模糊度固定模式下,5个测站E方向的提升明显,Galileo系统固定解模式下定位精度和收敛时间相对于浮点解状态有一定提升,加入BDS2/BDS3后5个测站E方向的定位精度提升率都在70%以上,另外两个方向效果没有E方向明显。【结论】模糊度固定是提升精密单点定位精度和快速收敛的主要因素之一,正确固定模糊度可以提升定位性能,加入BDS系统后相比单Galileo系统在定位性能及模糊度固定率方面有进一步的提升。

关键词: 精密单点定位, 模糊度固定, 相位偏差, 整数钟产品

Abstract:

[Objective] This study is aiming at non-integer features of ambiguity in traditional precise point positioning (PPP), accomplishing ambiguity-resolution based on integer clock products, verifying the influence of PPP ambiguity fixation on positioning performance of GAL-only and the improvement in orientation performance and ambiguity fixation rate under BDS/GAL combined mode. [Methods] Experimental verification is carried out based on real data. The positioning accuracy of PPP under the fixed ambiguity and improvement in ambiguity fixation rate are calculated under GAL-only and BDS/Galileo combined mode. [Results] Under GAL-only ambiguity fixed mode, the E direction of five stations improved significantly. after the addition of the BDS system, the improvement rate of positioning accuracy of five stations in direction E is more than 70%, and the effect of the other two directions is not as obvious as in direction E. [Conclusions] Ambiguity-resolution is one of the major factors to improve the precision and fast convergence of PPP. Correct ambiguity-resolution can improve positioning performance. Compared with GAL-only, the addition of the BDS system can enhance the positioning performance and ambiguity-resolution rate.

Key words: precise point positioning, ambiguity-resolution, uncalibrated phase delay, integer clock product
